Specifications • Colour: Red/Green with common cathode. Activate both colours to achieve orange • Size: 10mm • Lens: Diffused • Viewing Angle: 75 degrees • Wavelength: Red 625nm Green 570nm • Typical Forward Current: 20mA • Typical Forward Voltage: 2.0V • Luminous Intensity: 10mcd • Continuous Maximum Current: 30mA Resistor for 5VDC : 91.0Ω Resistor for 9VDC : 300.0Ω Resistor for 12VDC : 470.0Ω Active Component Details active mount type : Through Hole active connector type : Solder Legs component package : radial active number of legs : 3.0Count LED Section Details Colour Section : Red Wavelength : 625.0nm LED Section Details Colour Section : Green Wavelength : 570.0nm
| category_l3 | 10mm |
| category_map_id | 756 |
| price_exc | 5 |
| in_stock | 1 |
| lead_note | Available |
| manuals | https://media.jaycar.com.au/product/resources/ZD0256_datasheetMain_41527.pdf |
