You've got the camera, the console, the phone screen you want to stream — and your laptop just says 'no signal.' Frustrating. You shouldn't need a degree in AV integration to get HDMI content onto OBS.
The DA315 plugs straight into a USB port, shows up as a webcam-class device, and starts feeding 1080p video within seconds. No driver download. No fiddling with settings. UVC and UAC compliant, so Windows and macOS both pick it up natively.
It takes HDMI input up to 4K@30Hz and outputs 1080p over USB 2.0 — plenty for OBS, VLC, Amcap, or any platform that accepts a standard video source. Aluminium body, 21 grams, no external power brick. Toss it in a laptop bag and forget it's there.
One thing to check before you order: certain Canon EOS (6D, 6D Mark II, M10, Rebel) and Fujifilm models aren't supported. If you're running one of those, call us first and we'll sort the right alternative.
In stock now. Ships from our warehouse as soon as your order lands
| brand | Simplecom |
| model | DA315 |
| type | HDMI to USB Video Capture Card |
| hmi_input_resolution | Up to 3840x2160@30Hz |
| usb_output_resolution | Up to 1920x1080@30Hz |
| video_input_format | 8 / 10 / 12-bit Deep Color |
| video_output_mode | YUV / JPEG |
| audio_format | L-PCM |
| max_hmi_cable_length | 15m (AWG26 Standard HDMI Cable) |
| power | USB powered, 0.4A / 5VDC max |
| operating_temperature | -10 to +55 °C |
| dimensions | 64 x 28 x 13 mm |
| weight | 21.4 g |
| material | Alloy Aluminium |
| os_compatibility | Windows 10 (64-bit), macOS 10.9 or higher |
| min_cpu | Quad Core Intel Core i5 or higher (i7 recommended) |
| min_ram | 4 GB |
| min_gpu | NVIDIA GT630 or higher |
| compatible_software | OBS, VLC, Amcap, most mainstream capture software |
| not_compatible | Canon EOS 6D, 6D Mark II, M10, Rebel; certain Fujifilm models; YUY2 format |
