The sub-miniature wasn't enough headroom for your current draw. This miniature SPDT toggle pushes to 2A at 250VAC or 5A at 28VDC (resistive load) while still fitting tight panels. Solder tags, threaded bush, chrome-plated brass handle. -30°C to +85°C operating range. Bigger contacts, same clean throw
| brand | JAYCAR |
| sku | ST0335 |
| type | SPDT |
| size_class | Miniature |
| position | On-On |
| terminal_type | Solder tag with threaded bush |
| ac_rating | 2A @ 250VAC (resistive) |
| dc_rating | 5A @ 28VDC (resistive) |
| operating_temperature | -30°C to +85°C |
| case_material | Diallyl Phthalate (DAP), UL94V-0 |
| toggle_handle | Brass, chrome plated |
| bushing | Brass, nickel-plated |
| housing | Stainless steel |
| terminals | Brass, electro-tin plated |
| contacts | Silver-plated over copper alloy (standard); gold-plated over nickel-plated alloy available |
