Jaycar 10K Ohm Linear (B) Double Gang 24mm Potentiometer – PCB & Panel Mount

You've got a two-channel project on the bench and you need a pot that actually stays put. No wobble, no extra brackets, no 'it fell off after three solder joints.' This 10K linear double gang does the job and holds itself. Solder it into your PCB and it's rigid on its own — six contact points, centre pin offset from the outer terminals. Mount it to a panel with the 3/8" 32 T.H.D. bush and it sits flat. The 6.35mm shaft takes a grub screw or interference-fit knob, 38mm of it sticking out so you've got clearance for your enclosure. Pins are big enough to terminate screened cable if you're hard-wiring rather than PCB-mounting. 0.5W max. Standardised design — the engineering drawing is published, so your layout won't surprise you at assembly time

• 10K Ohm linear (B) taper, double gang, 24mm diameter
• Self-holding PCB mount — six contact points, no extra mechanical fixing needed
• 6.35mm shaft with 25% flat for grub-screw or interference-fit knob, 38mm long
• 3/8" 32 T.H.D. bush for secure panel mounting
• Pins sized to terminate screened cable for hard-wired builds
• 0.5W max power rating
