Jaycar 1000µF 10VDC Low ESR Electrolytic Capacitor – Radial Lead | RE6304

Your buck converter is running hot and the output ripple is creeping past spec. A standard electrolytic just won't cut it at this frequency – you need low impedance where it counts. This Jaycar 1000µF 10V low-ESR cap sits at 0.06Ω max impedance at 100 kHz and handles 1210 mA rms ripple at 105°C. That's the difference between a clean rail and a noisy one. Rated for 2,000 to 4,000 hours under load at 105°C, so it's not a throwaway part. Radial leads on standard pitch – drop it into your PCB and test the ripple again. Add to cart

• 1000µF at 10VDC with low-ESR design for clean switching-supply output
• Impedance: 0.06Ω max at 20°C, 100 kHz
• 1210 mA rms ripple current at 105°C, 100 kHz
• Low D.C. leakage current for stable biasing
• Rated 2,000–4,000 hours load life at 105°C
• Radial leads on standard pitch for through-hole PCB mounting
