Your UPS needs a firmware patch, a battery swap, or it's just flat on the floor. You can't pull power from 10 servers to fix one box. This panel routes mains straight through your rack while you work on the UPS — no downtime, no cold boots, no 3am panic call.
Hardwired in and out. No adapter hunting. 8× C13 outlets for standard server PSUs, 2× C19 for the high-draw gear. 125A line rating handles a full 4U server stack at 20 kVA without breaking a sweat. Circuit breaker on board, 99% efficiency so you're not paying for phantom load.
Rack-mounts in 4U. Ships with brackets, an install guide, and the manual. Plug in, wire up, done before your next standup
| 0 | CSA |
| 1 | GOST |
| 0 | Installation guide |
| 1 | Rack mounting brackets |
| 2 | User manual |
| brand | APC |
| model | SBP20KP |
| rack_units | 4U |
| input_type | Hardwire 3-wire (1P+N+E) and 5-wire (3P+N+E) |
| output_type | Hardwire 3-wire (H N+E) and 3-wire (2P+E) |
| outlets_c13 | 8 |
| outlets_c19 | 2 |
| max_line_current_a | 125 |
| load_capacity_va | 20000 |
| input_voltage | 200/208/220/230/240V single-phase; 380/400/415V three-phase |
| output_voltage | 200/208/220/230/240V |
| frequency_hz | 50/60 |
| efficiency_percent | 99 |
| protection | Circuit breaker |
| operating_temp_c | -20 to 50 |
| storage_temp_c | -40 to 65 |
| humidity_percent | 0–95 (non-condensing) |
| mounting | Rack mounted |
