Your network switch just dropped a port because the power dipped. You don't need another incident to fix. This APC Easy UPS On-Line slots into a 2U space, plugs in, and sits between your wall socket and everything that matters. Pure sine wave output at 2400W keeps routers, access points, and small server racks running through the flicker. Six C13 outlets and one C19 cover most rack gear without hunting for adapters. The intelligent card slot means you can watch battery state from your monitoring stack instead of guessing. Four minutes twenty-four seconds at full load — enough to save, log, and shut down in order. Rail kit's in the box. In the rack in ten minutes
| 0 | 1× IEC C19 to Schuko power cable |
| 1 | 1× IEC C13 to C14 power cable |
| 2 | 1× USB cable |
| 3 | 1× RS-232 configuration cable |
| 4 | 1× rack mounting bracket set |
| 5 | 1× rack mounting support rails |
| 6 | User manual |
| brand | APC |
| model_range | Easy UPS On-Line |
| rated_power_va | 3000 VA |
| rated_power_w | 2400 W |
| rack_units | 2U |
| topology | Double-conversion on-line |
| waveform | Pure sine wave |
| input_voltage | 230 V (220–240 V range) |
| output_voltage | 230 V (220–240 V range) |
| input_connector | IEC 60320 C20 |
| output_connectors | 6× IEC 60320 C13, 1× IEC 60320 C19 |
| runtime_at_full_load | 4 min 24 s @ 2400 W |
| min_max_load | 240–2400 W |
| replacement_battery | APCRBCV202 |
| compatible_nmc | AP9544, SRVSMB001, VGL9901I |
| management_connections | USB, RS-232, Intelligent Card Slot |
| bypass | Automatic and manual built-in |
| operating_temperature | 0–40 °C |
| storage_temperature | -20–50 °C |
| humidity_operating | 0–95% non-condensing |
| altitude_operating | 0–3000 m |
| acoustic_level | 50 dBA |
| heat_dissipation | 910 Btu/h |
| ip_rating | IP20 |
| mounting_mode | Rack mounted |
| cable_length | 1.48 m |
