Your rack's got the switch, two servers, a storage node. All humming along. Then the grid drops and you've got maybe three minutes before everything's dark. Not enough to finish a backup. Not enough to shut down clean.
The APC Easy UPS SRV1KRILRK-E is built for that exact moment. 4U rackmount unit with an external battery pack already wired in. At 900W full draw you get roughly 23 minutes and 43 seconds. That's time to finish the job, close the session, walk away.
Double-conversion online topology. Pure sine wave. Zero transfer time. Your gear never sees the dip.
Four IEC C13 outlets on the front. IEC C14 input. 230V single phase. LCD panel for voltage, load, battery state. Connect to EcoStruxure IT or your existing monitoring stack and you'll know about a grid issue before it hits the rack.
Automatic and manual bypass built in. Internal fault? Power reroutes through the bypass. No hard kill.
Rail kit and mounting brackets are in the box. Drop it into your 19-inch rack, tighten the rails, done. No separate hardware run to the hardware store.
In the box: IEC C13-to-Schuko cable, IEC C13-to-C14 cable, USB cable, RS-232 configuration cable, external battery pack, battery cable, rack mounting brackets, user manual.
Replacement battery: SRV36RLBP-9A. Compatible NMC cards: AP9544, SRVSMB001, VGL9901I. Compatible mounting: SRVRK1.
Add to cart and get your rack protected before the next storm season hits
| 0 | AP9544 |
| 1 | SRVSMB001 |
| 2 | VGL9901I |
| 0 | 1x IEC C13 to Schuko power cable |
| 1 | 1x IEC C13 to C14 power cable |
| 2 | 1x USB cable |
| 3 | 1x RS-232 configuration cable |
| 4 | 1x external battery pack |
| 5 | 1x battery cable |
| 6 | 1x rack mounting brackets |
| brand | APC |
| model | SRV1KRILRK-E |
| type | Online Double-Conversion UPS with Extended Battery Pack |
| form_factor | 4U Rackmount |
| rated_power_va | 1000 VA |
| rated_power_w | 900 W |
| input_voltage | 230 V (accepts 220–240 V) |
| output_voltage | 230 V (accepts 220–240 V) |
| input_connection | IEC 60320 C14 |
| output_outlets | 4x IEC 60320 C13 |
| rack_units | 4U |
| network_frequency | 40–70 Hz auto sensing |
| input_voltage_limits | 110–285 V (half load), 160–280 V (full load) |
| operating_temperature | 0–40 °C |
| storage_temperature | -20–50 °C |
| humidity | 0–95% non-condensing |
| operating_altitude | 0–3000 m |
| acoustic_level | 50 dBA |
| heat_dissipation | 372 Btu/h |
| ip_rating | IP20 |
| mounting | Rack mounted, compatible with SRVRK1 |
| replacement_battery | SRV36RLBP-9A |
| management | EcoStruxure IT or third-party platforms |
| bypass | Automatic and manual |
