Your server room can't survive another brownout. One voltage dip and you're explaining to the team why the network is down again. This APC Smart-UPS On-Line keeps pure sine wave power flowing through every glitch, spike, and full outage — zero transfer time, no switching gap.
10kVA/10kW true double-conversion on-line protection in a 6U rackmount chassis. Handles 3-phase 230V/400V input (also accepts 220V, 240V, 380V, 415V). Output is clean 230V sine wave with under 2% harmonic distortion and a 3:1 crest factor. Internal automatic and manual bypass lets you service the unit without dropping your load.
Six C13 and four C19 IEC outlets on the front panel. Hard-wire 3-wire (1P+N+E) or 5-wire (3P+N+E) input connection. Output frequency locks to 50/60 Hz ±3 Hz, synced to mains.
Comes with a Web/SNMP management card, an extra SmartSlot for additional connectivity, PowerChute Network Shutdown for graceful unattended shutdown, rail kit, temperature probe, USB cable, and full documentation. Extended runtime variant — pair with the APCRBC140 replacement battery when it's time.
Add to cart and keep your rack alive through the next storm
| brand | APC |
| model | SRT10KRMXLI |
| rated_power_va | 10000 VA |
| rated_power_w | 10000 W |
| input_voltage | 230V / 400V, 3-phase (also accepts 220V, 240V, 380V, 415V) |
| output_voltage | 230V (also 220V, 240V) |
| output_waveform | Pure sine wave |
| rack_units | 6U |
| output_outlets | 6x IEC C13, 4x IEC C19, 1x hard-wire 3-wire (H+N+E) |
| input_connectors | 1x hard-wire 3-wire (1P+N+E), 1x hard-wire 5-wire (3P+N+E) |
| bypass_type | Internal (automatic and manual) |
| harmonic_distortion | <2% |
| crest_factor | 3:1 |
| output_frequency | 50/60 Hz ±3 Hz, sync to mains |
| network_frequency | 40–70 Hz auto-sensing |
| operating_temperature | 0–40 °C |
| storage_temperature | -15–45 °C |
| humidity | 0–95% non-condensing |
| acoustic_level | 55 dBA |
| heat_dissipation | 1947 Btu/h |
| replacement_battery | APCRBC140 |
| compatible_spare_parts | ACF127, W870-8135 |
| compatible_wireless_adapter | AP9834 |
| included_accessories | Rail kit, Web/SNMP management card, temperature probe, USB cable, documentation, rack mounting brackets and support rails |
