CRADLEPOINT E400 ENTERPRISE BRANCH ROUTER

Cradlepoint E400 5-yr NetCloud Enterprise Branch Routing Essentials Plan, Advanced Plan, and E400 (5G Modem), Global

5G SA, SD-WAN, and security appliance for hybrid WAN enterprise sites

The Ericsson Cradlepoint E400 routing and security appliance is designed to connect fixed locations using the latest standards of Stand Alone 5G cellular, Wi-Fi 7, satellite, and wired links. The all-in-one form factor makes it easy to connect offices, branches, store, clinics and pop-up temporary locations to the internet and critical applications without the need for extra hardware or complicated configurations. The embedded 5G or LTE modem means that connectivity is always available from day one without waiting for a wired connection while the dual-SIM ensures continuous uptime for connectivity.


Category
Branch, fixed sites

Cloud management
Yes

Wireless connectivity
5G NR Rel-17 & Cat 20 LTE

5G status
5G embedded

Form factor
Industrial plastic

Ethernet ports
5 x 2.5 GbE

USB ports
1 x USB 2.0 (Type-A)

Serial ports 0
Dual-modem support
Not embedded; combine with 5G adapter using captive modem for dual modem​

Network operator standards
PTCRB — U.S. & Canada, GCF — global

Network operator certifications
AT&T, T-Mobile, Verizon

Regions
Varies by modem
See data sheet for countries served

Throughput
2.4 Gbps

VPN tunnel count
20

Wi-Fi
Tri-band, tri-concurrent; 802.11be Wi-Fi 7 (2x2x2)

GNSS
Passive

PoE
No

Operating temperature
0 °C to 40 °C (32 °F to 104 °F) with battery;
0 °C to 45 °C (32 °F to 113 °F) without battery

Rack mountable
No

Private cellular network
Yes — CBRS, 4G LTE, 5G

Battery option
Yes, up to 8-hour battery backup
