APC Back-UPS Pro, 650VA/390W, Tower, 230V, 6x IEC C13 outlets, AVR, LCD, User Replaceable Battery
This product is part of the Back-UPS Pro range. This 650VA UPS has 6 total that provide UPS power backup and surge protection. It features a built-in AVR and a LCD interface with audible alarms. Its runtime at 100 Watts is 25 minutes. The Back-UPS Pro family offers guaranteed power protection for high-performance computer systems, routers, external storage devices, game consoles, and other home and business electronics.
Run time for load 390 W
Min-max: 39-390 W 2min 44s
Max. Capacity Used 100 %
Main Input Voltage 230 V
Main Output Voltage 230 V
Rated power in W 390 W
Rated power in VA 650 VA
Input Connection Type IEC 60320 C13
Output connection type 6 IEC 60320 C13
Battery type Lead-acid battery
Network frequency 50/60 Hz +/- 3 Hz auto-sensing
Input voltage limits 176...294 V
Maximum input current 10 A
Switching current capacity 10 A
Maximum configurable power in W 390 W
Output frequency 50/60 Hz +/- 1 Hz sync to mains UPS type
Line interactive
Wave type Stepped approximation to a sinewave
Maximum configurable power in VA 650 VA
Transfer time 10 ms typical : 12 ms maximum
Ambient air temperature for operation 0…40 °C
Relative humidity 0…95 %
Operating altitude 0...10000 ft
Ambient air temperature for storage -15…45 °C
Storage Relative Humidity 0…95 %
Storage altitude 0.00…15240.00 m
Acoustic level 45 dBA
Heat dissipation 13.3 Btu/h
Noise suppression full time multi-pole noise filtering : 10% of IEEE surge let-through : zero clamping response time: instantaneous
Control panel- Multifunction LCD status and control console
Alarm- Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Mounting mode- Not rack mountable
Replacement Battery - APCRBC110
